HT Instruments SOLAR-KIT VDE testapparatuur-set (1002290)

For solar PV system installers and maintenance technicians, the HT Instruments SOLAR-KIT provides a complete solution for testing and verifying photovoltaic installations according to VDE standards. The kit combines the SOLAR300N multifunction tester, SOLAR02 remote irradiance and temperature unit, HT204D clamp meter, and TOPVIEW200 software for comprehensive analysis.

Key specifications

• Insulation test voltages: 250V, 500V, 1000V DC
• Insulation resistance range: up to 1000 MΩ
• Continuity test current: 200mA
• Open-circuit voltage (Voc) range: up to 1000V DC
• Short-circuit current (Isc) range: up to 10A DC
• Power measurement range: up to 100kW
• I-V curve tracing with graphical display and comparison to nominal data
• Irradiance and temperature measurement via wireless SOLAR02 unit
• Clamp meter (HT204D) current range: up to 400A AC/DC
• Data logging and USB connectivity
• Safety rating: CAT III 1000V, CAT II 1000V
• Power supply: rechargeable battery (SOLAR300N), standard batteries (SOLAR02/HT204D)

Why choose it

This kit enables complete verification of solar installations, from insulation and continuity to I-V curve analysis, all in one package. The wireless SOLAR02 unit ensures accurate irradiance and temperature measurements without additional wiring, while the TOPVIEW200 software facilitates detailed reporting.

Ideal use cases

• Commissioning new photovoltaic systems
• Periodic inspection and maintenance of solar arrays
• Troubleshooting performance issues in PV modules
• Generating test reports for compliance documentation

Good to know

The kit includes test leads, probes, alligator clips, MC3/MC4 adapters, a carrying case, and a calibration certificate. The SOLAR300N features a graphic LCD with backlight for clear readings in various lighting conditions.
