HP SVC AS PCA-controller Color Z

The HP SVC AS PCA-Controller Color Z is a high-performance storage controller designed for enterprise environments. It provides reliable data management and connectivity for HP server systems, ensuring optimal performance and scalability.

Advantages

This controller offers enhanced data transfer rates and robust RAID support, making it ideal for critical applications. Its PCIe interface ensures low latency and high bandwidth, while the included drivers simplify integration.

Suitable for

• HP ProLiant servers requiring advanced storage control
• Data centers needing reliable RAID configurations
• Enterprise environments with high I/O demands

Key specifications

• Brand: HP
• Model: 6CF14-67005
• MPN: 6CF14-67005
• EAN: 5715063389096
• Category: Controller
• Host Interface: PCIe
• Data Rate: 6 Gbps
• RAID Levels: 0, 1, 5, 6, 10, 50, 60
• Supported Storage Drive Interfaces: SAS, SATA
• PCI Card Form Factor: Low Profile
• Internal SATA Ports Quantity: 8
• SSD Support: Yes
• Logical Block Addressing (LBA) Support: Yes
• Compliance Certificates: RoHS
• Harmonized System (HS) Code: 84733020
• Windows Operating Systems Supported: Windows Server 2012, 2016, 2019
• Linux Operating Systems Supported: Red Hat Enterprise Linux, SUSE Linux Enterprise Server
• Server Operating Systems Supported: Windows Server, Linux
• Operating Temperature (T-T): 0 - 55 °C
• Storage Temperature (T-T): -40 - 70 °C
• Operating Relative Humidity (H-H): 5 - 90%
• Weight: 200 g
• Width: 167 mm
• Depth: 64 mm
• Height: 20 mm

Recommendations

For optimal performance, pair this controller with HP enterprise-grade SSDs and ensure your server BIOS is updated to the latest version. Always verify compatibility with your specific server model before installation.
