DSIT Roll..Profi kabelhaspel-afroller DS-Easyroll

Handling heavy cable drums on construction sites or in workshops often means wrestling with unwieldy reels, risking damage to cables and strain on workers. The DSIT Roll..Profi DS-Easyroll eliminates that struggle, providing a stable, low-friction platform that lets you unwind cable smoothly and safely, even from drums weighing up to 200 kg.

Who is it for

Professional electricians, construction crews, and industrial maintenance teams who regularly work with large cable drums will appreciate the DS-Easyroll's robust build and effortless operation. It's equally suited for workshops that need a reliable dispensing station for frequent cable cutting.

Main features

• Supports cable drums up to 200 kg, with a maximum diameter of 1000 mm and width of 620 mm.
• Two continuously adjustable steel rollers accommodate various drum sizes and types, including wooden, plastic, and steel reels.
• Ball bearing rollers ensure smooth, low-effort unwinding, reducing operator fatigue and preventing cable kinks.
• Powder-coated steel construction offers excellent corrosion resistance for long service life in demanding environments.
• Non-slip feet keep the dispenser stable during use, enhancing safety on uneven surfaces.

Specifications

• Load capacity: 200 kg
• Max. cable drum diameter: 1000 mm
• Max. cable drum width: 620 mm
• Number of rollers: 2 (adjustable)
• Roller material: Steel
• Roller diameter: 38 mm
• Bearings: Ball bearings
• Adjustability: Continuously adjustable rollers
• Non-slip feet: Yes
• Material: Powder-coated steel
• Corrosion resistance: Yes
• Compatibility: Wooden, plastic, and steel cable drums
• Application: Professional, construction sites, workshops, industry

Tips

For optimal performance, position the dispenser on a level surface and adjust the rollers so the drum sits evenly without touching the ground. Regularly check the rollers and bearings for debris to maintain smooth operation.
